AOG 24-B-06 Main Burner for 24", 30" and 36" Grills
Product Description
If your AOG grill has weak heat, uneven burner output, or a worn or damaged main burner, the AOG 24-B-06 is the replacement burner used in compatible 24", 30", and 36" built-in and portable grills.
The burner is made from 304-grade stainless steel and produces 15,000 BTUs. It measures 14 1/2" long by 6 7/8" wide. AOG 24" grills use two main burners, while 30" and 36" grills use three.
Key Features
- Replacement main burner for compatible AOG gas grills
- 304-grade stainless steel construction
- 15,000 BTU heat output per burner
- Used in both built-in and portable AOG grill configurations
Compatible AOG Grills
- 24" AOG built-in grills
- 24" AOG portable grills
- 30" AOG built-in grills
- 30" AOG portable grills
- 36" AOG built-in grills
- 36" AOG portable grills
Fitment and Ordering Notes
- Part number: 24-B-06
- 24" AOG grills use 2 main burners.
- 30" AOG grills use 3 main burners.
- 36" AOG grills use 3 main burners.
- Check the part number and physical dimensions of your existing burner before ordering when grill identification is uncertain.
Technical Specifications
| Specification | Detail |
|---|---|
| Brand | AOG |
| Part Number | 24-B-06 |
| Product Type | Main Grill Burner |
| Material | 304-Grade Stainless Steel |
| Heat Output | 15,000 BTUs |
| Dimensions | 14 1/2" L x 6 7/8" W |
| Quantity Used in 24" Grill | 2 |
| Quantity Used in 30" Grill | 3 |
| Quantity Used in 36" Grill | 3 |
Installation Notes
AOG's burner replacement instructions state that the grill must be completely cool and the gas supply completely shut off before burner removal. The cooking grids and flavor grids are removed to access the burner. The replacement burner must be positioned over the orifice fitting with the orifice centered inside the burner gas inlet, and the rear burner studs must seat correctly in the burner support before the burner clip and cooking components are reinstalled.
Frequently Asked Questions
What are signs that an AOG main burner may need replacement?
A burner should be inspected if it is physically damaged, badly deteriorated, or no longer producing normal burner output. Other grill components can also cause heating problems, so inspect the existing burner before ordering a replacement.
Does the 24-B-06 fit both built-in and portable AOG grills?
Yes. The available AOG parts information identifies this burner for compatible 24", 30", and 36" built-in and portable grill configurations.
How many 24-B-06 burners does my AOG grill use?
AOG 24" grills use two main burners. AOG 30" and 36" grills use three main burners.
Can I use the dimensions to confirm fitment?
The 14 1/2" L x 6 7/8" W dimensions are useful as a secondary check, but the part number and grill application should be used first when identifying the correct burner.
